The TH3361SS316 from General Electric is a Spec-Setter disconnect switch rated at 30 A, 3-pole, 600 VAC. It provides 200kA@600V interrupting rating.
Factory specification: disconnect, heavy duty safety switches, UL listed, 3PH, 3P, 4 wire, 600V, 30A, 200kA@600V, nema 4/4X stainless steel 316 enclosure, Fusible accepts class R fuses, Single style, suitable for outdoor use, disconnect safety switches.
TH3361SS316 Technical Specifications
| Manufacturer |
General Electric |
| Series |
Spec-Setter |
| Type |
Disconnect Switch |
| Voltage |
600 V |
| Amperage |
30 A |
| Poles |
3 |
| Phase |
3 |
| AIC Rating |
200kA@600V |
| Nema Rating |
4 |
| Configuration |
Single |
| Switch Style |
Fusible |
| Suit Fuse |
R |
| Wire |
4 |
Industrial Automation Co. offers the TH3361SS316 in New and IAC Certified Refurbished condition. Reach out to our sales team for availability, pricing, and lead time.
