[shortdesc] Dual-band 2.4 and 5 GHz support, 2.5 and 4 dBi gain, 6x RPSMA connectors, ceiling mount design, plenum rated enclosure [/shortdesc]
[properties]
| Model |
FANT-06ABGN-2504-O-R |
| Product Type |
Ceiling Mount Omnidirectional Antenna |
| Frequency Range |
2400–2483 MHz / 5150–5850 MHz |
| Gain |
2.5 dBi (2.4 GHz) / 4 dBi (5 GHz) |
| Antenna Pattern |
Omnidirectional |
| Polarization |
Vertical |
| Number of Ports |
6 |
| Connector Type |
RPSMA Male |
| Pigtail Length |
36 in. (91.44 cm) with connector |
| Environment |
Indoor – Plenum Rated |
| Mounting Method |
Ceiling Mount |
[/properties]
[specifications]
| Bandwidth |
83 MHz (2.4 GHz) / 700 MHz (5 GHz) |
| Vertical Beamwidth |
55° (2.4 GHz) / 60° (5 GHz) |
| Horizontal Beamwidth |
360° (2.4 GHz & 5 GHz) |
| VSWR |
≤ 2.0 (2.4 GHz) / ≤ 2.5 (5 GHz) |
| Nominal Impedance |
50 Ohms |
| Maximum Input Power |
50 Watts |
| Dimensions (L x W x H) |
7.1 x 5.1 x 1.9 in. (18.03 x 12.95 x 4.83 cm) |
| Weight |
0.68 lb (0.31 kg) |
| Operating Temperature |
-40°F to +158°F (-40°C to +70°C) |
[/specifications]
Clean Ceiling Coverage for High-Performance Indoor WiFi
The Fortinet FANT-06ABGN-2504-O-R is a dual-band omnidirectional ceiling mount antenna engineered for indoor environments where appearance, signal consistency, and compliance matter. Designed to pair seamlessly with Fortinet FortiAP access points, it delivers balanced 360-degree coverage across both 2.4 GHz and 5 GHz bands while maintaining a low-profile, professional finish.
With six integrated dual-band pigtails and RPSMA male connectors, this antenna fully supports modern multi-stream MIMO deployments, making it ideal for enterprise offices, healthcare facilities, and commercial buildings requiring reliable wireless performance without visual clutter.
Key Benefits & Features
-
Dual-Band Omni Coverage: Operates across 2400–2483 MHz and 5150–5850 MHz to support legacy and high-throughput WiFi clients with uniform 360-degree signal distribution.
-
Optimized MIMO Support: Six dual-band antenna leads enable efficient multi-radio connectivity for FortiAP models requiring multiple RF chains.
-
Low-Profile Ceiling Design: Purpose-built for ceiling installations where aesthetics and discreet placement are critical.
-
Plenum Rated Construction: Certified for installation in air-handling spaces, ensuring compliance with commercial building standards.
-
Enterprise-Grade Reliability: Rated for up to 50 W input power with stable performance across a wide operating temperature range.
Ideal Use Cases
- Corporate offices and enterprise campuses
- Hospitals, clinics, and healthcare facilities
- Hotels, conference centers, and meeting rooms
- Retail spaces requiring clean ceiling aesthetics
- Educational institutions and training centers
Technical Specifications
-
Frequency Range: 2400–2483 MHz and 5150–5850 MHz
-
Antenna Gain: 2.5 dBi at 2.4 GHz, 4 dBi at 5 GHz
-
Horizontal Beamwidth: 360 degrees
-
Vertical Beamwidth: 55 degrees at 2.4 GHz, 60 degrees at 5 GHz
-
Polarization: Vertical
-
Connectors: 6x RPSMA Male
-
Pigtail Length: 36 inches with connector
-
Mounting Type: Ceiling mount
-
Environment: Indoor, Plenum rated
Upgrade Your Indoor Wireless Coverage Today
Deploy clean, consistent WiFi coverage with Fortinet-grade reliability. Order the FANT-06ABGN-2504-O-R today.
