Description
The Schneider Electric FHL36080 is a three pole molded case circuit breaker designed for reliable protection of three-phase power distribution systems. It provides thermal magnetic protection with controlled long-time and instantaneous trip performance for industrial and commercial electrical applications.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Schneider Electric |
| Category |
Circuit Protection |
| Part Number |
FHL36080 |
| Subcategory |
Molded Case Circuit Breakers |
| Frame Type |
FHL |
| Amperage Rating |
80 A |
| Voltage Rating |
415 VAC |
| Number of Poles |
3 |
| Phase |
3 Phase |
| Breaking Capacity Code |
H |
| Protection Type |
Thermal Magnetic |
| Mounting Type |
Unit Mount |
| Magnetic Hold Current |
800 A |
| Magnetic Trip Current |
1450 A |
| Electrical Connection |
Line and Load Lugs |
| Terminal Identifier |
AL100FA |
| Phase Connection |
ABC |
| Application Rating |
HACR Rated |
| Dimensions (H x W x D) |
6.4 x 4.5 x 4.13 in |
| Weight |
5.07 lbs |
Information About FHL36080
The FHL36080 is part of the Schneider Electric FHL Series, developed for molded case circuit breaker applications requiring dependable overload and short-circuit protection. This breaker supports three-phase electrical systems with a continuous current rating of 80 amps at 415 VAC. It uses a thermal magnetic trip mechanism to provide coordinated long-time overload protection and instantaneous response to short-circuit conditions. The unit-mount design with line and load lugs allows secure installation in industrial enclosures and power distribution assemblies.
Key Features
- Thermal Magnetic Protection System: Combines thermal overload sensing with instantaneous magnetic tripping to protect circuits from sustained overcurrent and short-circuit faults.
- Three Pole Configuration: Ensures balanced protection across all phases in three-phase power distribution systems.
- H Breaking Capacity Design: Engineered to safely interrupt fault currents according to H-rated breaking capacity requirements.
- Unit Mount Construction: Provides secure mechanical mounting and reliable electrical connections in distribution panels.
- Defined Magnetic Trip Characteristics: Magnetic hold and trip current ratings support predictable and controlled fault response.
- HACR Rated Application: Approved for heating, air conditioning, and refrigeration circuit protection.
- Compact FHL Frame Design: Optimized for space-efficient installations while maintaining robust electrical performance.
The FHL36080 delivers the reliability and precision required for protecting three-phase power distribution circuits in industrial and commercial environments.
