Description
The Square D FH26060BC is a 2 Pole thermal magnetic molded case circuit breaker designed to protect single-phase industrial and commercial circuits. It delivers 60 Amps of current handling capacity and operates at voltages up to 600VAC and 250VDC. The FH26060BC is suited for I-Line panelboards, providing both long time and instantaneous trip functions to safeguard electrical systems efficiently.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Square D |
| Part Number |
FH26060BC |
| Category |
Circuit Breaker |
| Subcategory |
Molded Case |
| Series |
FH |
| Amperage |
60A |
| Voltage |
600VAC / 250VDC |
| Poles |
2 |
| Phase |
1 |
| Frame Type |
F Frame |
| Interrupting Rating |
25kAIC@480V |
| Connection Type |
I-Line Style Plug-In |
| Protection Type |
Thermal Magnetic |
| Trip Functions |
Long Time & Instantaneous |
| Terminal Connection |
Line and Load Lug |
| Wire Gauge |
14 to 1/0 AWG AL/CU |
| Temperature Rating |
-13–158°F (-25–70°C) |
| Magnetic Hold Current |
800A |
| Magnetic Tripping Current |
1450A |
| Dimensions (HxWxD) |
6.4 x 3 x 4.13 in (162.56 x 76.20 x 104.90 mm) |
| Certifications |
UL, CSA, NOM, IEC, CCC, CE |
| Weight |
6 lb |
Information About
FH26060BC
The FH26060BC is part of Square D’s FH series, built with a robust F-frame housing for durable performance in heavy-duty environments. It utilizes an I-Line style plug-in connection for compatibility with a wide range of panelboards and switchboards. Designed for 2-pole, single-phase circuits, it supports industrial, commercial, and utility applications requiring reliable overcurrent protection. The breaker incorporates thermal magnetic trip technology to detect both overloads and short-circuits quickly and accurately.
Key Features:
- Poles: 2 Pole configuration suitable for single-phase circuit protection.
- Current Rating: 60 Amps for moderate load circuits.
- Voltage Rating: 600VAC and 250VDC operational range.
- Interrupting Capacity: 25kAIC@480V for high fault-current tolerance.
- Trip Functions: Long time and instantaneous trip for precise protection.
- Connection Type: I-Line Style plug-in for secure and fast panel installation.
- Wire Compatibility: Supports 14 to 1/0 AWG AL/CU conductors.
- Certifications: UL, CSA, NOM, IEC, CCC, CE approved.
The FH26060BC delivers the reliability and precision required for industrial and commercial circuit protection.
