| AI Object Classification |
Classes: Person, Bicycle, Bus, Car, Motorbike, Train, Truck, Any Class
Sub-Classes (attributes): Person Clothing Color (Upper, Lower), Vehicle Color
Rules: Object Detected, Perimeter, Linger, Dwell, Abandoned/Removed, Enter, Exit, Crowd, Queue, Direction |
| Audio |
Bi-directional, 1x Line input and 1x Line output |
| Alarm Input/Output |
1x Alarm In and 1x Alarm Out |
| Backlight Compensation |
- |
| B/W |
- |
| Color |
- |
| Day/Night |
True Day/Night CF removal |
| Defog |
Supported |
| Digital Noise Reduction |
- |
| Dimensions |
Ø145x106.5mm (Ø5.71 x 4.19 in) (without mount plate)
Ø145.3x113.5mm (Ø5.72 x 4.47 in) (with mount plate) |
| Dynamic Range |
True multi shutter WDR up to 141 dB Off, TWDR, TWDR 3x, SmartWDR |
| Environment Rating |
IEC 60529 IP66, IEC 60529 IP67 IEC 62262 IK10 BS EN IEC 63000 ROHS, REACH, WEEE NEMA 250 Type 4x |
| Ethernet |
IEEE 802.3, 10/100Base-T Ethernet, RJ45, auto sensing |
| Field of View |
2MP: H: 98.47°(W) – 31.1°(T) V: 51.88°(W) – 17.55°(T)
5MP: H: 97.57°(W) – 31.74°(T) V: 70.26°(W) – 23.84°(T)
8MP: H: 112.1°(W) – 47.5°(T) V: 58.0°(W) – 26.6°(T) |
| Focal Length |
- |
| Focus |
- |
| Gain Control |
- |
| H.264 |
yes |
| H.265 |
yes |
| Horizontal FOV |
- |
| Housing Color |
Signal White Pantone RAL 9003 |
| Imager |
2MP: Sony 1/2.8” Progressive Scan CMOS imager
5MP: Sony 1/2.8” Progressive Scan CMOS imager
8MP: Sony 1/1.8” Progressive Scan CMOS imager |
| Image Stabilization |
Electronic image stabilization (EIS) using gyro sensor (coming soon) |
| IntelliZip |
- |
| IR |
- |
| IR Illuminator |
850 nm, Smart / Adaptive IR, up to 50m (164 ft) |
| Lens Type |
2MP: 2.7 mm – 13.5 mm, MFZ, P-Iris, F1.6(W) – F3.1(T)
5MP: 2.7 mm – 13.5 mm, MFZ, P-Iris , F1.31(W) – F2.37(T)
8MP: 3.6 – 11mm, MFZ, P-iris, F1.3(W) – F2.15(T)
One touch auto focus, manual, and automatic focus with zoom |
| Manual Speed |
- |
| Max Aperture |
- |
| Max Frame Rate |
2MP: 60/50 fps
5MP: 30/25 fps
8MP: 15/12.5 fps |
| Minimum Illumination |
2MP: Color: 0.05 lux, B/W: 0.005 lux
5/8MP: Color: 0.1 lux B/W: 0.01 lux |
| MJPEG |
yes |
| Motion Detection |
3 zones supported |
| Noise Reduction |
- |
| Onboard Storage |
microSDXC slot, Class 10 or better, up to 1TB supported (Card not included) Pre event / Post event 1- 10 sec Encrypted storage and streaming TrickleStor offline recording and backfilling |
| ONVIF Compliant |
- |
| Operating Temperature |
-50°C (-58°F) to +60° C (140°F) (IR off at +50° C/122° F) Start-up temperature: -40°C (-40°F) Humidity up to 95% RH, Non-Condensing |
| Outdoor Rating |
- |
| Pan Travel |
Pan 350°, Tilt 67°, Rotation 355° |
| Power Draw |
2MP
PoE
Typ. 0.1A / Max 0.21A
Typ. 4.5W / Max 10.0W
24VAC
Typ. 0.38A / Max 0.75A
Typ. 4.7W / Max 10.3W
5MP
PoE
Typ. 0.11A / Max 0.22A
Typ. 5.2W / Max 10.4W
24VAC
Typ. 0.43A / Max 0.78A
Typ. 5.4W / Max 10.7W
8MP
PoE
Typ. 0.12A / Max 0.25A
Typ. 5.5W / Max 12.0W
24VAC
Typ. 0.45A / Max 0.88A
Typ. 5.7W / Max 12.3W |
| Power Input |
PoE 802.3af (802.3at Type 1) Class 3 | 24VAC |
| Power Supply |
- |
| Presets |
- |
| Privacy Zones |
10 user definable rectangular zones |
| Resolution Options |
2MP: 16:9: 1920 x 1080 (2MP) to 480x272
5MP: 4:3: 2560 x 1920 (5MP) to 480x272
8MP: 16:9: 3840 x 2160 (8MP) to 480x272 |
| Shutter Speed |
- |
| Simultaneous Users |
10 users |
| Supported Protocols |
TCP/IP, IPv4, IPv6, TCP, UDP, HTTP, FTP, DHCP, WS-Discovery, DNS, DDNS, RTP, RTCP, RTSP, TLS, Unicast, Multicast, NTP, ICMP, IGMP, SMTP, WS-Security, IEEE 802.1x, PEAP, EAP-TLS, EAPoL, SSH, HTTPS, SOAP, WS-Addressing, CIFS, UPNP, LLDP, SIP, ARP, EAP-LEAP, QoS |
| S/N Ratio |
- |
| Tilt Travel |
- |
| Vandal-Resistant |
- |
| Video Streams |
Triple Streaming with a maximum of 5 concurrent shared streams |
| Weight |
Net 1.01 kg (2.23 lbs.), Gross 1.29 kg (2.84 lbs.) |
| White Balance |
- |
| Wide Dynamic Range |
- |
| Wi-Fi |
Micro USB via optional USB Wi-Fi Dongle IA-KIT-WD-UUA |
