Description
The Schneider Electric EDB24110 is a molded case circuit breaker designed to provide reliable overcurrent protection in commercial and industrial electrical systems. It features a 110 amp rating with a 480Y/277 VAC voltage capacity, making it suitable for branch and feeder circuit protection. This two-pole, bolt-on breaker is commonly used in panelboard applications where compact size and dependable performance are required.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Schneider Electric |
| Category |
Circuit Breaker |
| Part Number |
EDB24110 |
| Subcategory |
Molded Case Circuit Breaker |
| Series |
EDB |
| Frame Type |
E-Frame |
| Breaker Type |
Molded case |
| Current Rating |
110 A |
| Poles |
2 |
| Rated Voltage |
480Y/277 VAC |
| Mounting Style |
Bolt-on |
| Application Use |
Branch and feeder circuit protection |
| Trip Mechanism |
Thermal-magnetic |
| Weight |
2.00 lbs |
Information About EDB24110
The EDB24110 is part of the Schneider Electric EDB series, which consists of E-frame molded case circuit breakers engineered for space-efficient power distribution. It is constructed with a durable molded housing and a thermal-magnetic trip mechanism to ensure protection against overloads and short-circuit faults. The breaker is compatible with bolt-on mounting systems and integrates easily into standard panelboard configurations. Its design supports consistent operation in demanding electrical environments while maintaining ease of installation and maintenance.
Key Features:
- Molded Case Circuit Breaker: Provides dependable overcurrent and short-circuit protection.
- EDB Series E-Frame Design: Optimized for compact panelboard installations.
- 110 Amp Current Rating: Suitable for higher-load branch and feeder circuits.
- Two-Pole Configuration: Designed for two-phase or single-phase applications.
- 480Y/277 VAC Rating: Supports common commercial distribution voltages.
- Bolt-On Mounting: Ensures secure installation and stable electrical connections.
- Thermal-Magnetic Trip Unit: Delivers accurate response to overloads and fault conditions.
The EDB24110 delivers the reliability and precision required for consistent circuit protection in commercial and light industrial power distribution systems.
