Description
The Farenhyt ECS-RCU is a Remote Command Unit designed for use with Farenhyt Emergency Communication Systems (ECS). It integrates a supervised microphone, emergency message buttons, and programmable audio switches to enable rapid voice announcements and system control during critical events. This compact, high-performance unit supports direct connection to compatible FACP panels for reliable emergency paging and communication.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Farenhyt |
| Category |
Fire Alarm Systems |
| Part Number |
ECS-RCU |
| Subcategory |
Remote Command Unit |
| System Type |
Emergency Communication and Paging Unit |
| Microphone |
Supervised for continuous monitoring |
| Emergency Message Buttons |
8 programmable buttons |
| Audio Switches |
16 mappable zones |
| Connectivity |
4-wire SBUS and 2-wire VBUS |
| Compatibility |
IFP-2100ECS, IFP-300ECS, IFP-2000ECS, IFP-1000ECS, IFP-100ECS |
| Construction |
Integrated ECS-RVM and RA-100 annunciator assembly |
| Mounting |
Wall-mounted, compact form factor |
| Voltage |
24 VDC (from compatible FACP) |
| Operation Type |
Fully supervised for fault detection |
| Dimensions |
17.74 × 11.37 × 3.33 in (standard) |
| Alternate Dimensions |
30 × 20 × 6 in (packaged) |
| Weight |
16 lbs (unit) |
Information About ECS-RCU
The ECS-RCU is a Remote Command Unit from Farenhyt, built to interface seamlessly with the IFP-2100ECS, IFP-300ECS, IFP-2000ECS, IFP-1000ECS, and IFP-100ECS series control panels. Designed as a combination of the ECS-RVM Remote Voice Module and RA-100 annunciator, it offers full paging and annunciation functions through a single integrated unit. Its architecture supports supervised communication pathways via SBUS and VBUS connections, ensuring fault-tolerant system performance. The unit’s compact profile allows installation in environments where a standard local operator console (LOC) may not fit, providing flexibility without compromising functionality.
Key Features:
- Integrated Voice and Control Functions: Combines Remote Voice Module and annunciator functions for centralized communication.
- Supervised Microphone: Ensures continuous line integrity and operational readiness for emergency paging.
- Emergency Messaging: Eight programmable buttons provide fast access to pre-recorded communication messages.
- Mappable Audio Switches: Sixteen assignable audio zones for flexible system configuration and zoning.
- Reliable Connectivity: Communicates with control panels via 4-wire SBUS and 2-wire VBUS links.
- Compact Form Factor: Smaller footprint ideal for installations with limited space.
- Panel Compatibility: Works with Farenhyt IFP-ECS Series fire alarm and emergency communication systems.
- Durable Construction: Built for demanding safety environments with supervised circuitry.
- The ECS-RCU delivers the reliability and precision required for critical emergency communication and system coordination.
