Description
The SICK DRS60E4A05000 is an incremental rotary encoder designed to deliver precise position and speed feedback in industrial motion control systems. Featuring a 60 mm housing with a face flange and 10 mm solid shaft, it provides high-resolution output at 5000 pulses per revolution. This encoder is engineered for reliable operation in demanding automation environments.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
SICK |
| Category |
Industrial Sensors |
| Part Number |
DRS60E4A05000 |
| Subcategory |
Rotary Encoders |
| Encoder Type |
Incremental |
| Series |
DRS60 CoreTech |
| Resolution |
5000 pulses per revolution |
| Signal Output |
HTL |
| Supply Voltage |
10–32 V DC |
| Housing Diameter |
60 mm |
| Mounting Type |
Face flange |
| Shaft Type |
Solid shaft |
| Shaft Diameter |
10 mm |
| Electrical Connection |
Quick disconnect |
| Application |
Industrial motion control and automation |
| Weight |
Approx. 0.35 kg |
Information About DRS60E4A05000
The DRS60E4A05000 is part of SICK’s DRS60 CoreTech series, developed for accurate and robust incremental encoding applications. It utilizes HTL signal technology, making it compatible with a wide range of PLCs, drives, and control systems operating on 10–32 V DC. The encoder is equipped with a face flange mounting and a solid shaft for secure mechanical coupling. Its quick-disconnect electrical interface simplifies installation and maintenance in industrial machinery and production systems.
Key Features:
- Incremental Rotary Encoder: Provides precise speed and position feedback for motion control.
- 5000 PPR Resolution: Supports high-resolution signal output for accurate system control.
- HTL Output Signals: Ensures compatibility with standard industrial control electronics.
- 10–32 V DC Supply Voltage: Suitable for common industrial power environments.
- 60 mm Housing Size: Standard encoder form factor for versatile machine integration.
- Face Flange Mounting: Enables secure and precise installation on machinery.
- 10 mm Solid Shaft: Allows direct and stable mechanical coupling to drives or motors.
- Quick Disconnect Interface: Simplifies wiring, replacement, and maintenance tasks.
- CoreTech Series Design: Built for reliable performance in continuous industrial operation.
The DRS60E4A05000 delivers the reliability and precision required for industrial motion feedback, automation, and drive control applications.
