Description
The Cognex DM302L is a high-performance fixed-mount barcode scanner from the DataMan 300 series, equipped with a liquid lens and designed for fast, precise decoding of 1D and 2D symbologies in demanding industrial environments.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Cognex |
| Category |
|
| Part Number |
DM302L
|
| Subcategory |
Fixed-Mount Barcode Scanners |
| Sensor Type |
1/1.8" CMOS |
| Lens Type |
Liquid Lens (Autofocus) |
| Image Resolution |
1280 x 1024 pixels |
| Frame Rate |
Up to 60 FPS |
| Symbologies (1D) |
Codabar, Code 39/128/93, Interleaved 2 of 5, MSI, GS1, UPC/EAN/JAN, Postal |
| Communication Interfaces |
Ethernet, RS-232 |
| Power Supply |
24 VDC, 20 W Max |
| Environmental Rating |
IP65/IP67 |
| Weight |
1.4 lbs |
Information About DM302L
The DM302L barcode scanner utilizes a liquid lens system that offers dynamic autofocus capabilities, making it ideal for applications with variable working distances. It supports advanced barcode decoding algorithms, providing reliable performance on poor-quality or damaged codes. With Ethernet and RS-232 connectivity, the scanner can be seamlessly integrated into existing networks and control systems. Operating at 24VDC with a maximum power draw of 20W, this device is both energy-efficient and rugged enough for 24/7 industrial use. It is compatible with most industrial protocols and supports a wide range of barcode types, from Codabar and UPC to GS1 DataBar and Postal codes.
Key Features:
- Liquid Lens Autofocus: Enables rapid and automatic focus adjustments for varying distances without mechanical wear.
- High Resolution Imaging: 1.3 MP CMOS sensor (1280 x 1024) captures fine details and supports high-density code reading.
- Fast Image Acquisition: Up to 60 FPS ensures responsive performance on high-speed production lines.
- Code Compatibility: Reads a broad set of 1D symbologies including Code 39, Code 128, GS1, and more.
- Rugged Design: Built to withstand industrial environments with a reliable 24V DC power requirement and up to 20W power draw.
- Versatile Communication: Offers Ethernet and RS-232 interfaces for flexible integration with industrial automation systems.
The DM302L is ideal for manufacturers requiring compact, intelligent scanning solutions with dynamic focus adjustment.
