Dell A20 ReadyRails 1U Sliding 2/4-Post Rail Kit – FKRDD / 0FKRDD
The Dell A20 ReadyRails 1U Sliding Rail Kit (FKRDD / 0FKRDD) is a tool-less mounting solution designed for 1U Dell servers. It supports both 2-post and 4-post racks and allows the system to fully extend out of the rack for easy servicing and maintenance.
Key Specifications
| Attribute |
Detail |
| Rail Type |
Sliding Rails |
| Rack Height |
1U |
| Rack Compatibility |
2-Post & 4-Post Racks |
| Mounting Interface |
Tool-less for square or unthreaded round holes |
| Threaded Rack Support |
Tooled installation (adapter bracket may be required) |
| Serviceability |
Full extension for internal component access |
| CMA Support |
Optional Cable Management Arm (sold separately) |
| Max Load Capacity |
Up to 100 kg (approx. 220 lbs) |
| Rack Standard |
19" EIA-310-E compliant racks |
| Package Includes |
2 outer rails, 2 inner rails |
Installation & Rack Compatibility
4-Post Racks
-
Tool-less installation for square or unthreaded round holes
-
Threaded racks require screws or optional adapter bracket kit
-
Supports full sliding extension for maintenance
2-Post (Telco) Racks
This flexibility makes the A20 rail kit suitable for a wide range of enterprise rack environments.
Compatible Dell PowerEdge Servers
R2xx Series
-
Dell PowerEdge R210
-
Dell PowerEdge R210 II
-
Dell PowerEdge R220
-
Dell PowerEdge R230
-
Dell PowerEdge R240
-
Dell PowerEdge R250
-
Dell PowerEdge R260
R3xx Series
-
Dell PowerEdge R310
-
Dell PowerEdge R320
-
Dell PowerEdge R330
-
Dell PowerEdge R340
-
Dell PowerEdge R350
-
Dell PowerEdge R360
R4xx Series
-
Dell PowerEdge R410
-
Dell PowerEdge R415
-
Dell PowerEdge R420
-
Dell PowerEdge R430
-
Dell PowerEdge R440
-
Dell PowerEdge R450
R6xx Series
-
Dell PowerEdge R620
-
Dell PowerEdge R630
-
Dell PowerEdge R640
-
Dell PowerEdge R6415
-
Dell PowerEdge R650xs
-
Dell PowerEdge R6515
-
Dell PowerEdge R660xs
Compatible XR-Series Servers
-
Dell PowerEdge XR11
-
Dell PowerEdge XR12
Compatible Dell PowerVault & Other Systems
PowerVault
-
Dell PowerVault DX6104 CSN
-
Dell PowerVault DX6104 SCN
-
Dell PowerVault DX6104 SN
-
Dell PowerVault NX300
-
Dell PowerVault NX3340
-
Dell PowerVault NX440
Other Nodes
-
Dell BSN Controller Node
-
Dell BSN Services Node
-
Dell PowerEdge HS5610
Ideal Use Cases
-
Enterprise data centers
-
Colocation facilities
-
Telecom / 2-post rack environments
-
Service-friendly server deployments
-
High-density 1U rack installations
