[shortdesc] 10 total Gigabit Ethernet ports, 6 PoE+ ports, 2 4PPoE ports, 2 combo uplinks, 240W PoE budget, DIN rail mount[/shortdesc]

[properties]

Brand	Cisco
Model	Catalyst IE3100 Rugged Series
SKU	IE-3100-6P2U2C-E
Product Type	Managed switch
Series	IE3100
Form Factor	DIN Rail
Port Count	10
Interface	6 GE PoE+, 2 GE 4PPoE, 2 GE Combo uplinks
PoE Support	PoE/PoE+/4PPoE
PoE Power Budget	240W
Dimensions	5.00 x 3.00 x 5.08 in. (12.70 x 7.62 x 12.90 cm)
Weight	2.3 lb (1.04 kg)
Input Voltage	12V to 54V nominal, 9.6V to 60V absolute

[/properties]

[specifications]

Software License	Network Essentials
Forwarding Rate	14.88 Mpps
Forwarding Bandwidth	10 Gbps
DRAM	4 GB
Flash	1.5 GB
SD Card Capacity	1 GB, 4 GB, 16 GB
Alarms	2 dry-contact alarm inputs
Console Ports	1 RS-232 via RJ-45, 1 Micro USB
Power Input	Dual DC Inputs
Power Consumption	26W
Maximum Current	6.1 A with 12V input, 7.5 A with 24V input, 5.8 A with 54V input
Inrush Current	80 A for 1 ms with 12V, 24V, or 48V input
Operating Temperature	-40° to 75°C (-40° to 167°F)
Operating Humidity	5% to 95% noncondensing
Protection Rating	IP30
MTBF	491,786 hours

[/specifications]

[accesories]

Compatible Accessories	SD-IE-1GB=, SD-IE-16GB=
Optional Power Supply	PWR-IE50W-AC=, PWR-IE50W-AC-L=, PWR-IE50W-AC-IEC=, PWR-IE65W-PC-AC=, PWR-IE65W-PC-DC=, PWR-IE170W-PC-AC=, PWR-IE240W-PCAC-L=, PWR-IE240W-AC-IEC=, PWR-IE480W-PCAC-L=, PWR-IE400W-AC-IEC=

[/accesories]

Rugged Gigabit Switching for Industrial Networks

The Cisco IE-3100-6P2U2C-E Catalyst IE3100 Rugged Series switch delivers managed Gigabit Ethernet connectivity in a compact DIN rail form factor for demanding industrial and extended enterprise environments.

Key Benefits and Features

• Provides 10 total Gigabit Ethernet ports for industrial network edge deployments.
• Supports 6 PoE+ ports and 2 4PPoE ports for powered devices.
• Offers a 240W PoE power budget for IP cameras, access points, sensors, and phones.
• Runs Cisco Network Essentials with Layer 2 switching, security, QoS, and management features.
• Fanless rugged design supports operation from -40°F to 167°F.

Ideal Use Cases

• Industrial Ethernet networks in manufacturing and automation environments.
• PoE deployments for IP cameras, PTZ cameras, wireless access points, and sensors.
• Transportation, energy, warehouse, and outdoor edge connectivity.
• Space constrained DIN rail installations requiring managed Gigabit switching.

Technical Specifications

• Brand: Cisco
• SKU: IE-3100-6P2U2C-E
• Product Type: Managed industrial Ethernet switch
• Total Ports: 10
• Downlink Ports: 6 x 10/100/1000 PoE+ RJ-45 and 2 x 10/100/1000 4PPoE RJ-45
• Uplink Ports: 2 Gigabit combo SFP/RJ-45 uplinks
• PoE Budget: 240W
• Forwarding Bandwidth: 10 Gbps
• Forwarding Rate: 14.88 Mpps
• Mounting: DIN rail mountable

Build a Rugged Cisco Industrial Network Edge

Choose the Cisco IE-3100-6P2U2C-E for managed Gigabit connectivity, PoE device support, and rugged industrial deployment flexibility.
