Description
The Omron C200HG-CPU63-E is a programmable PLC CPU module designed for SYSMAC C200HG automation systems requiring modular expansion and serial communication support. The C200HG-CPU63-E provides up to 15.2K words of program capacity with RS-232C communication for industrial control applications. It is built for backplane-mounted PLC architectures in manufacturing and machine automation environments.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Omron Automation and Safety |
| Category |
Automation Control Modules |
| Part Number |
C200HG-CPU63-E |
| Subcategory |
PLC CPU Modules |
| Series |
SYSMAC C200HG |
| Module Type |
CPU Programmable Controller Module |
| Program Capacity |
15.2K Words |
| Memory Size |
6K Words Data Memory |
| Expandable System Capacity |
Up to 16 Modules (3 Racks Max) |
| Supply Voltage |
100–120 / 200–240 VAC, 24 VDC |
| Communication Port |
RS-232C |
| Mounting Type |
Backplane / Rack Mount |
| Memory Backup |
Battery Backup Included |
| Ingress Protection |
IP30 |
| Operating Temperature Range |
0°C to 55°C |
| Approvals |
CE, CSA, UL |
| Manufacturer Status |
Discontinued by Manufacturer |
| Weight |
0.85 lbs |
Information About C200HG-CPU63-E
The C200HG-CPU63-E is part of the Omron SYSMAC C200HG series, engineered as a CPU programmable controller module for large-scale modular PLC installations. It supports expansion up to 16 modules across multiple racks, allowing scalable I/O and control system growth. The unit operates on wide-range AC or DC supply voltages and includes built-in battery backup for memory retention in critical automation processes. With RS-232C communication capability and optional interface cards, it is designed for integration into legacy industrial networks and controller architectures where stable processing and modular design are required.
Key Features:
-
SYSMAC C200HG CPU Module: Programmable controller CPU designed for Omron modular PLC systems.
-
Large Program Capacity: Supports up to 15.2K words program memory for complex automation logic.
-
Modular Expansion Support: Allows installation of up to 16 modules across multiple PLC racks.
-
RS-232C Communication Interface: Provides serial connectivity for programming and device integration.
-
Backplane Mounting Design: Built for rack-based PLC control panels and modular architectures.
-
Battery Backup Functionality: Maintains memory retention for critical control programs.
-
Wide Supply Voltage Compatibility: Operates on AC or 24VDC supply input configurations.
-
Industrial Temperature Rating: Designed for operation from 0°C to 55°C in automation environments.
The C200HG-CPU63-E delivers the reliability and precision required for modular PLC CPU control in industrial automation and legacy SYSMAC systems.
