Boltswitch T466-6C: a 600 A, 4-pole, 600 VAC T Series bolted pressure switch. It provides 200kA@600V interrupting rating.
Factory specification: Geneva, dual operator, open type bolted pressure, for non-interruptible power supplies,4P, 4W, 600VAC, 600A, 200kA@600V, nema 1, Fusible accepts class T fuses, Single branch style, suitable for use with dead front switchboards, switchboards and switchgear distribution systems.
T466-6C Technical Specifications
| Manufacturer |
Boltswitch |
| Series |
T Series |
| Type |
Bolted Pressure Switch |
| Voltage |
600 V |
| Amperage |
600 A |
| Poles |
4 |
| Phase |
3 |
| AIC Rating |
200kA@600V |
| Nema Rating |
1 |
| Configuration |
Single |
| Switch Style |
Fusible |
| Suit Fuse |
T |
Industrial Automation Co. offers the T466-6C in New and IAC Certified Refurbished condition. Reach out to our sales team for availability, pricing, and lead time.
