The SLB3413G4 from Boltswitch is a SLB Series bolted pressure switch rated at 4000 A, 3-pole, 240 VAC. It provides 200kA@240V interrupting rating.
Factory specification: bottom-feed bolted pressure with integral ground fault protection, 3P, 4W, 240/120V, 4000A, 200kA@240V, nema 1, Fusible accepts class L fuses, Single branch style, suitable for use with deadfront switchboards, switchboards and switchgear distribution systems.
SLB3413G4 Technical Specifications
| Manufacturer |
Boltswitch |
| Series |
SLB Series |
| Type |
Bolted Pressure Switch |
| Voltage |
240 V |
| Amperage |
4000 A |
| Poles |
3 |
| Phase |
3 |
| AIC Rating |
200kA@240V |
| Nema Rating |
1 |
| Configuration |
Single |
| Switch Style |
Fusible |
| Suit Fuse |
L |
Industrial Automation Co. offers the SLB3413G4 in New and IAC Certified Refurbished condition. Reach out to our sales team for availability, pricing, and lead time.
