[shortdesc] 4x 5 MP 1/2" sensors, 360° panoramic view, Forensic WDR, Lightfinder 2.0, AI edge analytics, Axis Edge Vault security [/shortdesc]

[properties]

Model	AXIS Q6300-E Panoramic Camera
SKU	02943-001
Product Type	Panoramic multidirectional camera with 360° overview
Image Sensor	4 × 1/2" progressive scan RGB CMOS; 2.9 µm pixel size
Effective Resolution	4 × 2592 × 1944 (5 MP) to 320 × 240 per sensor; default 2592 × 1944
Lens	3.7 mm, F2.0; M14 mount; fixed iris; autofocus; minimum focus distance 1.0 m (3.3 ft)
Field of View	360° overall; horizontal 108.4° per sensor; vertical 84°
Day and Night	Automatic IR-cut filter
Minimum Illumination	Color: 0.06 lux at 50 IRE, F2.0; B/W: 0.03 lux at 50 IRE, F2.0
Shutter Speed	1/66500 s to 2 s
Wide Dynamic Range	Forensic WDR up to 120 dB (depending on scene)
Image Processing	Axis Zipstream, Forensic WDR, Lightfinder 2.0; 2D/3D noise reduction; scene profiles: outdoor, indoor, forensic
Video Compression	H.264 (Baseline, Main, High); H.265 (Main); Motion JPEG
Max Frame Rate	Up to 30 fps (50/60 Hz) in all resolutions
Video Streams	Up to 20 unique, configurable video streams; controllable frame rate and bandwidth; low latency mode
Processing Platform	Dual ARTPEC-8 SoC with deep learning processing unit (DLPU); 8 GB RAM; 8 GB Flash
Built-in Analytics	AXIS Object Analytics; AXIS Scene Metadata; AXIS Audio Analytics; AXIS Video Motion Detection; active tampering alarm
Audio Features	Speaker pairing; directional audio detection with PTZ redirection
Network Interface	Shielded RJ45 10BASE-T/100BASE-TX/1000BASE-T with Power over Ethernet (PoE)
Edge Storage	microSD/microSDHC/microSDXC card slot; SD card encryption (AES-XTS-Plain64 256-bit); NAS recording support
Ingress / Impact Protection	IP66; NEMA 4X; IK10; NEMA TS 2; ISO 12944-6 C5; ISO 21207 (Method B)
Power	With Solo kit: PoE IEEE 802.3bt 60 W (typ. 14.3 W, max 47.3 W); with PTZ camera: PoE IEEE 802.3bt 90 W or AXIS High PoE 120 W (typ. 29.3 W, max 80–103.4 W)
Operating Conditions	Panoramic camera with Solo kit: −50 °C to 55 °C (−58 °F to 131 °F); with PTZ camera and PoE 90 W: −30 °C to 55 °C (−22 °F to 131 °F); with Axis High PoE 120 W: −50 °C to 55 °C (−58 °F to 131 °F); humidity 10–100% RH (condensing)
Storage Conditions	−40 °C to 65 °C (−40 °F to 149 °F); 5–95% RH (non-condensing)
Effective Projected Area (EPA)	0.047 m² (0.5 ft²)
Dimensions (Ø × H)	Approx. Ø 361 mm (14.2 in) × 179.1 mm (7.05 in) with cover ring
Weight	4.0 kg (8.8 lb)

[/properties]

[specifications]

Camera Adjustment	Pan ±180°; tilt −40° to +75°; rotation ±95°
Signal-to-Noise Ratio	>55 dB
Image Settings	Saturation, contrast, brightness, sharpness, white balance, day/night threshold, local contrast, tone mapping, exposure mode and zones, defog, compression, rotation 0°/90°/180°/270° (corridor format), text and image overlay, dynamic overlays, overlay widget, up to 32 polygon privacy masks including mosaic masks
Video Streaming Features	Axis Zipstream for H.264/H.265; VBR/ABR/MBR; low latency mode; video streaming indicator; up to 20 unique streams
Network Protocols	IPv4, IPv6, HTTP/HTTPS, HTTP/2, TLS, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3, DNS/DNSv6, DDNS, NTP, PTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMP, RTCP, DHCPv4/v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, secure syslog, Link-Local (ZeroConf)
System Integration	Open API with VAPIX and AXIS Camera Application Platform (ACAP); ONVIF Profiles G, M, S, T; compatible with AXIS Camera Station Edge/Pro and leading third-party VMS
Event Triggers	Application, device status, directional audio detection, edge storage, I/O manual trigger and virtual inputs, MQTT, PTZ status, schedules, video events (day/night mode, tampering, bitrate degradation)
Event Actions	Autopilot control, day/night mode switching, defog mode, directional audio-driven PTZ move, image and video clip upload (FTP/SFTP/HTTP/HTTPS/network share/email), status LED, MQTT messages, HTTP/HTTPS/TCP notifications, overlay text, SNMP traps, recording, security erase
Cybersecurity – Edge	Axis Edge Vault platform; signed OS; secure boot; encrypted filesystem (AES-XTS-Plain64 256-bit); secure keystore in certified hardware (CC EAL 6+, FIPS 140-3 Level 3); Axis device ID; signed video
Cybersecurity – Network	IEEE 802.1X (EAP-TLS, PEAP-MSCHAPv2); IEEE 802.1AE MACsec (PSK/EAP-TLS); IEEE 802.1AR; HTTPS/HSTS; TLS 1.2/1.3; Network Time Security (NTS); X.509 certificate support; host-based firewall
Regulatory Approvals	Product markings: UL/cUL, CE, KC, EAC, VCCI, RCM; EMC: CISPR 35, CISPR 32 Class A, EN 55035, EN 55032 Class A, EN 50121-4, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A; Railway: IEC 62236-4
Safety & Environmental	Safety: CAN/CSA C22.2 No. 62368-1 ed. 3, IEC/EN/UL 62368-1 ed. 3; Environmental: IEC 60068-2-1/2/6/14/27/78; IEC/EN 60529 IP66; IEC/EN 62262 IK10; NEMA 250 Type 4X; NEMA TS 2 (2.2.7–2.2.9); ISO 12944-6 C5; ISO 21207 (Method B)
Connectors	Shielded RJ45 10BASE-T/100BASE-TX/1000BASE-T PoE; USB port for Wi-Fi dongle (Mediatek MT7612U-based)
Storage & Recording	Support for microSD/microSDHC/microSDXC card with encryption; recording to network-attached storage (NAS); optimized for AXIS Surveillance Cards
Operating Temperature Details	Panoramic camera with Solo kit: −50 °C to 55 °C (start-up −40 °C); with PTZ camera on PoE 90 W: −30 °C to 55 °C (start-up −30 °C); with Axis High PoE 120 W: −50 °C to 55 °C (start-up −40 °C)
Languages	English, German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese, Polish, Traditional Chinese, Dutch, Czech, Swedish, Finnish, Turkish, Thai, Vietnamese

[/specifications]

[accesories]

Included in the Box	Camera; adapter bracket; installation guide; owner authentication key (included in the box)
Optional – Lenses	Lens M14 7.6 mm F2.0 IR (HFOV 58.5°); Lens M14 14.1 mm F2.0 IR (HFOV 31°); Lens M14 21.4 mm F2.0 IR (HFOV 19.9°); Lens M14 30.8 mm F2.4 IR (HFOV 13.8°)
Optional – Installation Tool	AXIS T8415 Wireless Installation Tool
Optional – Storage	AXIS Surveillance Cards (microSD/microSDHC/microSDXC)

[/accesories]

AI Powered 360° Awareness for Demanding Sites

The Axis Q6300-E Panoramic Camera 02943-001 combines four 5 MP 1/2" sensors into a single 360° overview, delivering sharp multi-directional coverage for high-risk locations. Paired with recommended AXIS Q61/Q63/P56-E PTZ cameras, operators can jump from full-scene awareness to zoomed details in a single click for faster incident response. Deep learning analytics, directional audio detection, and hardened cybersecurity make it ideal for professional video surveillance deployments.

Key Benefits & Features

• 360° multi-sensor coverage: Four 5 MP sensors with a shared 3.7 mm F2.0 lens provide continuous 360° horizontal and 84° vertical fields of view, reducing blind spots and the number of cameras needed on site.
• AI enhanced edge analytics: Dual ARTPEC-8 SoCs with a deep learning processing unit power AXIS Object Analytics, scene metadata, and video motion detection for accurate detection of people and vehicles at the edge.
• Autopilot and directional audio detection: The camera can trigger an integrated PTZ to move toward detected motion or sudden audio incidents, helping operators verify events in real time.
• Outstanding image quality in challenging light: Forensic WDR up to 120 dB and Lightfinder 2.0 deliver detail in scenes with strong contrasts and low light, while 2D and 3D noise reduction keep bandwidth controlled.
• Hardened cybersecurity and reliability: Axis Edge Vault with secure boot, signed OS, secure keystore, and encrypted storage protects device identity and video integrity, backed by outdoor-ready IP66, NEMA 4X, and IK10 housing.

Ideal Use Cases

• Wide area monitoring for city squares, campuses, and transport hubs that need full 360° situational awareness.
• Perimeter and fence line protection when paired with PTZ for long-range identification.
• Industrial plants, logistics yards, and ports requiring overview plus fast zoom on critical assets.
• Commercial buildings and business parks where security teams need automated analytics and event-driven PTZ control.

Technical Specifications

• Image sensor: 4 x 1/2" progressive scan RGB CMOS, 2.9 μm pixel size.
• Resolution and frame rate: 4 x 2592 x 1944 up to 30 fps in all resolutions.
• Lens and field of view: 3.7 mm F2.0 lens, 360° horizontal and 84° vertical field of view with autofocus and fixed iris.
• Minimum illumination: Color 0.06 lux, B/W 0.03 lux at 50 IRE, F2.0.
• Imaging technologies: Forensic WDR up to 120 dB, Lightfinder 2.0, Axis Zipstream with H.264/H.265, 2D/3D noise reduction.
• Analytics: AXIS Object Analytics, AXIS Scene Metadata, AXIS Audio Analytics, directional audio detection, and active tampering alarm.
• Cybersecurity: Axis Edge Vault with secure boot, signed OS, secure keystore, and signed video support.
• Power and PoE: PoE IEEE 802.3bt 60 W for solo kit; with PTZ, PoE 90 W or AXIS High PoE 120 W, typical 14.3–29.3 W consumption.
• Environmental rating: IP66, NEMA 4X, IK10, ISO 12944-6 C5 corrosion protection; supports operating temperatures from −50 °C to 55 °C depending on power method.
• Edge storage: microSD/microSDHC/microSDXC support with AES-XTS-Plain64 256bit encryption and NAS recording.

Secure Your Site with Axis Q6300-E Today

Deploy the Axis Q6300-E Panoramic Camera 02943-001 for AI-driven 360° awareness, seamless PTZ integration, and hardened protection of your most critical areas. Order today to upgrade your surveillance capabilities.
