The ASRock Rack 4U18N-AM5/2T is a high-density 4U rackmount server enclosure that supports up to 18 nodes, each powered by an AMD AM5 socket processor. It is designed for virtualization, cloud computing, and high-end enterprise applications.
Specifications
Model Number: 4U18N-AM5/2T
Brand: ASRock
Alt Part Number(s): 4U18N-AM5/2T
Product Type: Barebone Server
Technical Description
Brand: ASRock
Model Number: 4U18N-AM5/2T
Processor Type: AMD EPYC 4004 and Ryzen 9000/8000/7000 series
Processor Socket: AM5 (LGA1718)
Processor Core: 288 Core
Processor Power: 1170W
Chipset Type: AMD B650
Motherboard: AM5D4ID-2T/BCM
Networking: 2 RJ45 10GbE ports (Broadcom BCM57416)
Drive Bays: 2 × 2.5" NVMe SSD,1 × M.2 NVMe (PCIe 5.0 x4),36 × 2.5" NVMe
Graphics Controller: ASPEED AST2600 BMC
Number of Node: 18 Node
Memory Capacity: 48GB Per Slot (192GB)
Memory Supported: up to ~3.46TB (192GB × 18 nodes)
Memory Technology: DDR5
Memory Channels: 36 Channels
Memory Slots: 4 x DIMM
Cooling: 5 × 80mm hot-swap fans
Power Supply: 2+2 Redundant 2000W 80-PLUS RPSU Platinum
Form Factor: 4U Rackmount
