APC AP7911 Switched Rack PDU – 2U, 30A, 208V, 16 C13 Outlets

High-Capacity Power Distribution for Enterprise IT Environments

---

Overview:

The APC AP7911 is a 2U rackmountable Switched Rack Power Distribution Unit (PDU) designed to deliver reliable and efficient power distribution for high-density IT equipment in data centers and server rooms. With 16 IEC 60320 C13 outlets, it provides ample connectivity for multiple devices, ensuring stable power delivery and enhanced equipment uptime.

Key Features:

• Input Voltage: 208V AC

• Input Current: 30A (derated to 24A in North America)

• Output Voltage: 208V AC

• Output Connections: 16 x IEC 60320 C13

• Input Connector: NEMA L6-30P

• Cord Length: 12.14 ft (3.7 meters)

• Rack Height: 2U

• Dimensions (WxDxH): 17.48 x 10.0 x 3.5 inches (444 x 254 x 89 mm)

• Weight: 13.93 lbs (6.32 kg)

• Color: BlackeBayAPC+1Excess UPS+1server-rack-online.com

Environmental Specifications:

• Operating Temperature: 32°F to 113°F (0°C to 45°C)

• Operating Relative Humidity: 0% to 95%

• Operating Elevation: 0 to 10,000 ft (0 to 3,048 meters)

• Storage Temperature: -25°C to 65°C

• Storage Relative Humidity: 0% to 95%

• Storage Elevation: 0 to 50,000 ft (0 to 15,240 meters)server-rack-online.com+1APC+1APC+1server-rack-online.com+1

Certifications:

The APC AP7911 is compliant with various industry standards, ensuring safety and reliability in demanding environments.

Applications:

Ideal for use in data centers, server rooms, and other IT environments requiring efficient and reliable power distribution. The AP7911 is suitable for powering servers, networking equipment, and other critical devices.
