Description
The Honeywell AML24FBA2AA04 is an AML24 Series SPDT rocker switch designed for panel-mounted control applications. It features an ON-OFF-ON switching function with a 3A rating at 125 VAC and 2A at 24 VDC. Designed for use with an illuminated actuator cap, it supports flexible operator interface configurations in industrial equipment.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Honeywell |
| Category |
Electromechanical Components |
| Part Number |
AML24FBA2AA04 |
| Subcategory |
Rocker Switches |
| Series |
AML24 |
| Contact Form |
SPDT |
| Switch Function |
ON - OFF - ON |
| Current Rating AC |
3 A |
| Current Rating DC |
2 A |
| Voltage Rating AC |
125 VAC |
| Voltage Rating DC |
24 VDC |
| Actuator Type |
Arm (Cap Required - Illuminated) |
| Illumination Type |
Incandescent |
| Mounting Type |
Panel Mount, Snap-In |
| Termination Style |
Solder or 0.110 in (2.8 mm) Quick Connect |
| Panel Cutout Dimensions |
28.98 mm x 19.05 mm (Rectangular) |
| Weight |
0.08 lb |
Information About AML24FBA2AA04
The AML24FBA2AA04 is part of Honeywell’s AML24 modular rocker switch family, engineered for industrial operator interface panels and control systems. It incorporates a single pole double throw (SPDT) contact configuration, enabling maintained ON-OFF-ON switching for dual-circuit control. The switch requires a compatible illuminated actuator cap and utilizes an internal incandescent lamp for visual indication. Designed for snap-in panel mounting, it supports solder or 0.110 in (2.8 mm) quick connect terminals for adaptable wiring options.
Key Features:
- SPDT Contact Configuration: Provides versatile control with ON-OFF-ON maintained positions.
- 3A at 125 VAC Rating: Suitable for industrial AC control circuits.
- 2A at 24 VDC Rating: Supports low-voltage DC applications.
- Illuminated Cap Design: Compatible with AML24 illuminated actuator caps.
- Incandescent Illumination: Enables visual status indication when configured with cap.
- Snap-In Panel Mount: Allows efficient and secure installation.
- Dual Termination Options: Solder or 0.110 in (2.8 mm) quick connect terminals.
- Standard Rectangular Cutout: Fits 28.98 mm x 19.05 mm panel openings.
The AML24FBA2AA04 delivers the reliability and precision required for industrial control panel and operator interface applications.
