Description
The PN-382035 is a discontinued main control board used in Allen-Bradley PowerFlex 755 drives, Frames 1 through 7. It handles core communication and control functions, including Ethernet/IP connectivity and configuration via rotary switch. This board ensures consistent operation in variable frequency drive (VFD) applications.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Allen-Bradley |
| Category |
PLCs/Machine Control |
| Part Number |
PN-382035 |
| Subcategory |
Main Control Board |
| Series |
PowerFlex 755 |
| Product Type |
Main Control PC Board |
| Communication |
Ethernet/IP |
| Compatible Drives |
PowerFlex 755 |
| Frame Compatibility |
Frame Sizes 1–7 |
| Configuration |
Rotary Switch |
| Application |
Variable Frequency Drives (VFDs) |
| Operating Temperature |
0°C to 40°C (32°F to 104°F) |
| Storage Temperature |
0°C to 40°C (32°F to 104°F) |
| Maximum Humidity |
80% RH, non-condensing |
| Maximum Installation Altitude |
1000 m (3281 ft) |
| Weight |
1.00 lb (0.45 kg) |
Information About PN-382035
The PN-382035 is a dedicated control board for PowerFlex 755 AC drives, compatible with frame sizes 1 through 7. Designed by Rockwell Automation, it provides Ethernet/IP communication and rotary switch-based configuration for quick and accurate setup. This board enables seamless integration into PLC-controlled systems, supporting precise motor control in industrial automation. Though no longer in production, it remains a critical replacement component for existing PowerFlex 755 units.
Key Features:
- Drive Compatibility: Supports PowerFlex 755 drives, Frames 1–7.
- Main Control Function: Central board managing communication and drive logic.
- Ethernet/IP Support: Enables high-speed industrial network connectivity.
- Rotary Switch Setup: Allows manual configuration of node addresses or parameters.
- Rockwell OEM Part: Original board designed for Allen-Bradley systems.
- Compact and Lightweight: 1 lb for easy handling and replacement.
- Discontinued Status: Still valuable for servicing legacy drive installations.
- The PN-382035 delivers the reliability and advanced networking required for effective VFD control in industrial environments.
