Description

The Cisco AIR-CAP3702I-B-K9 is a dual-band 802.11ac Wave 1 wireless access point from the Aironet 3700 Series, designed for indoor enterprise environments.





Technical Specifications

Condition	New/Never Used Surplus
Brand	Cisco
Category	Network Hardware
Part Number	AIR-CAP3702I-B-K9
Subcategory	Wireless Access Point (Indoor, Dual-Band, 802.11ac)
Form Factor	External
Power Over Ethernet (PoE)	PoE+
Wi-Fi Bands	2.4 GHz, 5 GHz
Wireless Protocol	802.11a/b/g/n/ac Wave 1 (draft 5.0)
Connector Type	RJ-45
Type	1000Base-T
Type	Management
Humidity Range Operating	10 - 90% (non-condensing)
Max Operating Temperature	104 °F
Min Operating Temperature	32 °F
Power Consumption Operational	15 Watt
Flash Memory	64 MB
RAM	512 MB
Depth	8.7 in
Height	2.1 in
Width	8.7 in
Weight	2.49 lbs





Information About AIR-CAP3702I-B-K9

The Cisco AIR-CAP3702I-B-K9 is a high-performance, enterprise-grade wireless access point from the Aironet 3700 Series, designed to deliver 802.11ac Wave 1 wireless connectivity in indoor environments. This model is equipped with internal antennas and supports dual-band operation, offering seamless mobility, high-speed wireless access, and advanced RF capabilities ideal for high-density enterprise and campus networks.

Key Features:

• Product Type: Indoor Wireless Access Point

• Wireless Standards:

  • 802.11ac Wave 1 (5 GHz band, up to 1.3 Gbps)

  • 802.11n (2.4 GHz band, up to 450 Mbps)

  • Backward compatible with 802.11a/b/g

• Antennas:

  • Internal antennas (integrated in the "I" model)

• MIMO Support:

  • 3x4 MIMO with 3 spatial streams

• ClientLink 3.0:

  • Enhances performance for all client types, including legacy devices

• CleanAir Technology:

  • Detects and avoids RF interference for improved performance

• Power Options:

  • Supports 802.3at PoE+ and 802.3af PoE

• Deployment:

  • Controller-based, requires a Cisco Wireless LAN Controller (WLC)

• Security:

  • Supports WPA/WPA2, 802.1X authentication, and rogue AP detection

• Interface:

  • 1 x 10/100/1000 Ethernet port (RJ-45)

The Cisco AIR-CAP3702I-B-K9 combines advanced RF intelligence, high throughput, and reliable dual-band connectivity, making it a powerful solution for scalable, controller-managed enterprise wireless networks across a wide range of indoor deployment scenarios.
