Description
The Cisco AIR-ANT2430V-R is a high-performance indoor antenna engineered to enhance wireless coverage in the 2.4 GHz frequency band. This triple omni-directional antenna delivers 3 dBi of gain and supports vertical polarization, ensuring robust and consistent signal propagation in demanding enterprise environments.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Cisco
|
| Category |
|
| Part Number |
AIR-ANT2430V-R |
| Subcatecory |
|
| Frequency Range |
|
| Antenna Type |
Omni-Directional |
| Gain |
3 dBi |
| Polarization |
Vertical |
| Connector Type |
3 x RP-TNC |
| Mounting Style |
Ceiling/Wall Mount |
| Material |
UV Stabilized Plastic Radome |
| Color |
White |
| Operating Temperature |
-30°C to 70°C |
| Humidity |
0% to 95% (Non-Condensing) |
| Length |
29.2 cm (11.5 inches) |
| Diameter |
5.1 cm (2 inches) |
| Max Power |
2 Watts |
| Impedance |
50 Ohms |
| Weight |
1.68 lbs |
Information About AIR-ANT2430V-R
The AIR-ANT2430V-R is designed specifically for use with Cisco Aironet Access Points, delivering reliable RF performance across a wide indoor coverage area. With a frequency range of 2.4 GHz, this 3 dBi gain antenna provides balanced signal distribution ideal for applications such as conference rooms, hallways, and open office environments.
Key Features:
- Triple RP-TNC Connectors: Enables multi-chain connectivity to support MIMO technology and optimize wireless performance in enterprise environments.
- 3 dBi Omni-Directional Gain: Offers balanced signal distribution, making it suitable for areas requiring consistent coverage such as offices and classrooms.
- 2.4 GHz Vertical Polarization: Ensures optimal compatibility with standard Wi-Fi equipment, improving signal clarity and reach.
- Durable Construction: Encased in a UV-stabilized radome, this antenna resists discoloration and degradation in indoor light-exposed environments.
- Versatile Mounting Options: Supports ceiling or wall installations for flexible deployment in diverse layouts and infrastructure designs.
- Wide Temperature and Humidity Tolerance: Operates reliably in conditions ranging from -30°C to 70°C and up to 95% non-condensing humidity.
The AIR-ANT2430V-R enables high-efficiency wireless coverage for Cisco Aironet deployments, contributing to dependable enterprise-class connectivity.
