Description
The Square D 8502SDO2V08 is a NEMA-rated magnetic contactor designed for full-voltage, non-reversing motor control in industrial and commercial power systems. Rated at 45 amps and up to 600 VAC, this three-pole contactor supports reliable switching for three-phase loads. It is equipped with a 208 VAC control coil and open-style construction for panel and surface-mounted installations.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Square D |
| Category |
Industrial Control |
| Part Number |
8502SDO2V08 |
| Subcategory |
Magnetic Contactors |
| Series |
8502 |
| Product Type |
NEMA Magnetic Contactor |
| NEMA Size |
Size 2 |
| Rated Current |
45 A |
| Number of Poles |
3 |
| Phase |
Three Phase |
| Maximum Voltage |
600 VAC |
| Coil Voltage |
208 VAC @ 60 Hz |
| Action |
Non-Reversing |
| Mounting Type |
Panel / Surface |
| Terminal Type |
Screw Clamp |
| Enclosure Type |
Open |
| Standards |
NEMA, UL, CSA, CE |
| Height |
5.13 in |
| Width |
4.31 in |
| Depth |
4.94 in |
| Weight |
5.5 lb (approx.) |
Information About 8502SDO2V08
The 8502SDO2V08 is part of Square D’s 8502 Type S contactor series, built to NEMA standards for durability and consistent performance in demanding environments. This NEMA Size 2 contactor is intended for non-reversing motor control applications and features a magnetic coil with screw clamp terminals for secure wiring. It is suitable for use across a range of motor horsepower ratings at multiple voltages, supporting infrastructure, industrial, and building automation systems. Designed for three-phase operation, the contactor meets UL, CSA, and CE approvals for compliant electrical installations.
Key Features:
- 45 Amp Rated Current: Supports reliable switching for medium-duty motor and load control.
- Three-Pole Configuration: Designed for three-phase power applications.
- 600 VAC Maximum Voltage: Suitable for high-voltage industrial power systems.
- NEMA Size 2 Rating: Built to NEMA standards for durability and performance consistency.
- Non-Reversing Operation: Intended for full-voltage motor starting and stopping.
- 208 VAC Control Coil: Compatible with standard control circuit voltages at 60 Hz.
- Screw Clamp Terminals: Provides secure and straightforward conductor termination.
The 8502SDO2V08 delivers the reliability and precision required for industrial motor control and power switching applications.
