Description
The 700-HC14Z24 is a general-purpose (GP) ice cube relay from Allen-Bradley, equipped with a 24V DC coil and a 4-pole double-throw (4PDT) contact configuration.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Allen-Bradley
|
| Category |
|
| Part Number |
700-HC14Z24
|
| Subcatecory |
|
| Amperage |
7 Amp |
Contact Configuration
|
4 NO, 8 NC |
| Standard |
CCC,CE,CSA,CUL,KC,UL |
| Coil Voltage |
24 V |
| Contact Rating |
Gold Contacts |
| Type |
Ice Cube |
| Weight |
0.04 lbs |
Information About 700-HC14Z24
The Allen-Bradley 700-HC14Z24 is a general-purpose miniature ice cube relay featuring a 24V DC coil and a 4-pole double-throw (4PDT) contact configuration. It is designed for reliable switching in industrial control applications, offering a compact solution with plug-in mounting for easy installation and maintenance.
Key Features:
-
Coil Voltage: 24V DC
-
Contact Configuration: 4PDT (4 Form C)
-
Contact Rating: 7 A at 250V AC / 30V DC
-
Contact Material: Gold-plated silver nickel (AgNi + 5 µm Au)
-
Mechanical Life: 50 million operations
-
Electrical Life: 100,000 operations minimum
-
Mounting Type: Plug-in (14-blade terminal)
-
Dimensions (H x W x D): 37.2 mm x 27.7 mm x 20.7 mm
-
Operating Temperature Range: -30°C to +55°C
-
Protection Rating: IP20
This relay is suitable for applications requiring reliable low-energy switching, such as PLC interfacing and signal isolation. Its gold-plated contacts ensure dependable performance in low-voltage circuits.
