Description
The Siemens 6ES7972‑0BA50‑0XA0 is a compact, 90°‑angled PROFIBUS bus connector designed for SIMATIC DP systems and supporting high-speed data communication up to 12 Mbit/s.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Siemens
|
| Category |
Components |
| Part Number |
6ES7972-0BB12-0XA0
|
| Subcategory |
Connector/Terminal/Pin |
| Product Type |
Bus Connector for PROFIBUS |
| Series |
SIMATIC DP |
| Data Transmission Rate |
Up to 12 Mbit/s |
| Cable Outlet |
90° angled |
| Dimensions (W x H x D) |
15.8 mm x 72.2 mm x 36.4 mm |
| Connection Technology |
FastConnect (IDC – Insulation Displacement Connector) |
| Terminating Resistor |
Integrated, switchable |
| Bus Connection Interface |
9-pin SUB-D male |
| Mounting Type |
Screw fastening |
| Housing Material |
Plastic
|
| Protection Class |
IP20 |
| Operating Temperature Range |
–25 °C to +60 °C |
| Weight |
0.057 kgs |
Information About 6ES7972-0BA50-0XA0
The Siemens 6ES7972-0BA50-0XA0 is a reliable PROFIBUS connector designed for SIMATIC DP systems in industrial automation. With a 90° angled cable outlet and FastConnect insulation-displacement technology, it offers fast, secure, and solderless wiring for PROFIBUS DP networks. This model is streamlined for installations that do not require a PG (programming device) port, making it ideal for compact and cost-effective setups.
Key Features:
-
Product Type: PROFIBUS Connector
-
Series: SIMATIC DP
-
Data Transmission Rate: Up to 12 Mbit/s
-
Cable Outlet: 90° angled
-
Bus Interface: 9-pin SUB-D (male) for device connection
-
PG Port: Not included
-
Terminating Resistor: Integrated, switchable via slide switch
-
Connection Technology: FastConnect IDC (insulation-displacement contact)
-
Dimensions (W x H x D): 15.8 mm x 72.2 mm x 36.4 mm
-
Mounting Type: Screw fastening
-
Housing Material: Plastic
-
Protection Class: IP20
-
Operating Temperature: –25 °C to +60 °C
-
Certifications: UL, RoHS compliant (successor model)
This PROFIBUS connector is an excellent solution for industrial applications requiring rapid, tool-free wiring without diagnostics access. Its durable build, secure mounting, and straightforward termination make it especially well-suited for mid-segment or end-device installations where PG interfacing is not required. Although now discontinued, it remains compatible with many legacy systems, and its successor ensures continuity in performance and compliance for modern requirements.
