Description
The Allen-Bradley 6200P-12WS3C1 is an industrial-grade Panel PC from the VersaView 6200 series, designed for reliable operation in rugged manufacturing environments.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Allen-Bradley
|
| Category |
PLCs/Machine Control |
| Part Number |
6200P-12WS3C1 |
| Subcatecory |
|
|
|
Multi-Touch Screen |
Memory
|
128 GB MLC SSD |
|
Temperature Rating
|
0 - 55 degrees C |
| Input Voltage |
12 - 24 VDC |
| Power Supply |
24 VDC |
| Type |
Integrated Display, Panel |
| Monitor Size |
12.1-inch Widescreen Display |
| Hard Disk |
128 GB |
| Networking Specification |
10/100/1000 Mbit |
| I/O Ports |
USB, Ethernet, Serial |
| RAM Memory |
4 GB |
| Speed |
1.91 GHz |
| Height |
266 mm |
| Width |
328 mm |
| Length |
97.1 mm |
| Weight |
11.00 lbs |
Information About 6200P-12WS3C1
The Allen-Bradley 6200P-12WS3C1 is an industrial panel PC from the VersaView® 5400 series, purpose-built for machine-level and distributed Human-Machine Interface (HMI) applications in automation environments. Featuring a compact, rugged design and modern computing capabilities, this unit supports high-resolution visualization and efficient system interaction across a range of industrial tasks.
Key Features:
-
Display: 12.1-inch widescreen LCD with a 16:9 aspect ratio, delivering clear and vibrant HMI visuals.
-
Touchscreen Technology: Projected Capacitive (PCAP) multi-touch interface ensures responsive user interaction, even in harsh conditions.
-
Resolution: 1280 x 800 pixels for crisp and detailed visualization of industrial processes.
-
Processor: Powered by a quad-core Intel® Atom™ E3845 processor at 1.91 GHz for smooth multitasking and application performance.
-
Memory: 4 GB DDR3 RAM supports reliable operation of SCADA/HMI software and other industrial applications.
-
Storage: 128 GB MLC Solid-State Drive (SSD) offers robust data storage and fast system boot times.
-
Operating System: Pre-installed with Windows 10 IoT Enterprise 64-bit, optimized for industrial use and long-term OS support.
-
Power Input: Operates on 24 VDC, compatible with standard industrial power systems.
-
Connectivity:
-
1 x DisplayPort for external display integration
-
2 x USB 2.0 and 1 x USB 3.0 for peripheral connectivity
-
1 x RS-232 serial port for legacy device communication
-
2 x Gigabit Ethernet ports for high-speed network access and redundancy
-
Mounting Options: Panel-mountable configuration allows secure integration into control cabinets or enclosures.
-
Certifications: Complies with cULus, CE, and RoHS standards, supporting global deployment in regulated environments.
The 6200P-12WS3C1 integrates seamlessly into Rockwell Automation environments and supports FactoryTalk® View ME/SE, ThinManager®, and other automation software. Its industrial-grade construction ensures durability in vibration- and dust-prone settings, making it ideal for machine builders, system integrators, and OEMs targeting high-performance HMI systems.
