Description
The Siemens 3VA4160-6ED34-0AA0 is a 3-pole molded case circuit breaker designed for reliable circuit protection in industrial and commercial electrical systems. Rated at 60 amps and 600 volts AC, it offers a high interrupting capacity of 65kA at 480V, ensuring dependable performance under heavy load conditions. This model includes thermal magnetic trip protection and a bolt-on connection for secure installation and consistent operation.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Siemens |
| Category |
Circuit Protection |
| Part Number |
3VA4160-6ED34-0AA0 |
| Subcategory |
Molded Case Circuit Breakers |
| Series |
3VA4 |
| Frame Type |
3VA41 |
| Amperage Rating |
60A |
| Voltage Rating |
600VAC |
| Poles |
3 |
| Interrupting Rating |
25kA @ 600Y/347V, 65kA @ 480V |
| Protection Type |
Thermal Magnetic (TM210 Trip Unit) |
| Functions |
Long-Time and Instantaneous Trip |
| Connection Type |
Bolt-On |
| Terminal Type |
Load Side Lug |
| Enclosure Rating |
IP40 |
| Wire Range |
8 to 3/0 AWG (Cu/Al) |
| Frequency Rating |
50/60 Hz |
| Temperature Range |
-25°C to +70°C |
| Phase |
3 |
| Standards Compliance |
UL 489, CSA C22.2 |
| Country of Origin |
Mexico |
| Dimensions (H×W×D) |
5.1 × 3 × 3 in |
| Weight |
1.63 lbs |
Information About 3VA4160-6ED34-0AA0
The 3VA4160-6ED34-0AA0 is part of Siemens’ 3VA4 Series, known for its advanced thermal magnetic technology and flexible system integration. Built for demanding low-voltage power distribution environments, it provides both long-time overload and instantaneous short-circuit protection. Its bolt-on design and 3-pole configuration make it compatible with a wide range of electrical panels and industrial control systems. With a compact footprint and UL/CSA certification, the breaker ensures high performance, durability, and compliance with global standards.
Key Features:
- High Interrupting Capacity: Rated for 65kA at 480V to ensure protection in high-fault environments.
- Thermal Magnetic Protection: Provides long-time overload and instantaneous short-circuit protection.
- Compact 3VA41 Frame: Saves space while maintaining high electrical performance.
- Wide Voltage Range: Operates up to 600VAC for industrial and commercial applications.
- Bolt-On Connection: Ensures secure and stable mounting with reliable current transfer.
- UL and CSA Certified: Meets North American safety and performance standards.
- Temperature Resilience: Performs efficiently between -25°C and +70°C.
- Versatile Wire Compatibility: Supports 8 to 3/0 AWG copper or aluminum conductors.
The 3VA4160-6ED34-0AA0 delivers the reliability and precision required for modern low-voltage power protection systems.
