Description
The TE Connectivity 27E891 is an 8-pin relay socket designed for KRPA series relays and supports both DIN rail and panel mounting. It features screw-type terminals for secure electrical connections and is rated for up to 10 A at 240 VAC.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
TE Connectivity
|
| Category |
|
| Part Number |
27E891 |
| Subcatecory |
|
| Compatible Relays |
KRPA Series |
| Number of Pins |
8 |
| Number of Poles |
2 |
| Terminal Type |
Screw Terminals |
| Mounting Type |
DIN Rail / Panel Mount |
| Rated Current |
10 A |
| Rated Voltage |
240 VAC |
| Standards Compliance |
RoHS, ELV |
| Weight |
2 oz |
Information About 27E891
The 27E891 is a relay socket built to accommodate 2-pole, 8-pin KRPA relays in control systems requiring DIN rail or panel mounting. The socket uses screw clamp terminals for stable, maintenance-friendly wiring and supports up to 10 A of current at 240 VAC. It complies with RoHS and ELV environmental standards, ensuring safe and sustainable component use. The snap-mount design allows for fast and tool-free installation onto standard DIN rails.
Key Features:
- 8-Pin Configuration: compatible with KRPA relays and other matching 8-pin relay types.
- Dual Mounting Options: supports both DIN rail and panel mounting for installation flexibility.
- Screw Terminals: provides reliable and secure wire terminations using standard screw-type connections.
- Rated for 10 A at 240 VAC: supports moderate relay loads in control circuits.
- Standards Compliant: RoHS and ELV compliant for eco-friendly and globally approved usage.
- TE Connectivity Quality: part number 2-1419106-3 ensures verified compatibility and build consistency.
The 27E891 offers secure relay interfacing, flexible mounting, and reliable electrical performance in industrial automation and control systems.
