Description
The Federal Signal 225XL-120-240B is a hazardous location LED flashing warning light operating on 120–240 VAC. Featuring a blue polycarbonate dome and rugged zinc housing, it provides bright, long-life visual alerts for industrial and outdoor safety applications.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Federal Signal |
| Category |
Signaling Devices |
| Part Number |
225XL-120-240B |
| Subcategory |
LED Warning Lights |
| Series |
Electraray 225XL |
| Light Source |
LED |
| Color |
Blue |
| Voltage Rating |
120–240 VAC |
| Flash Rate |
60 Flashes per Minute |
| Luminous Intensity |
238 Candlepower |
| Average Life |
50,000 Hours |
| Mode |
Flashing (Configurable to Steady-Burn) |
| Mounting |
1/2-Inch NPT Pipe |
| Housing Material |
Zinc Base with Polycarbonate Dome |
| Shape |
Cylindrical |
| Dimensions |
5.5 in W x 5.5 in D x 7.5 in H |
| Environmental Rating |
NEMA 4X, IP66, IP69K |
| Operating Temperature |
-58°F to 150°F (-50°C to 65°C) |
| Certifications |
UL Listed, cUL Listed, Marine Listed |
| Application |
Hazardous Location Visual Signaling |
| Weight |
4.8 lb (approx.) |
Information About 225XL-120-240B
The 225XL-120-240B is part of Federal Signal’s Electraray Series, engineered for hazardous location signaling where reliability and durability are essential. Designed with a sealed Type 4X, IP66, and IP69K enclosure, it withstands exposure to dust, water, and harsh environments. This cylindrical unit uses high-efficiency LEDs with a rated life of 50,000 hours and delivers 60 flashes per minute. Suitable for both indoor and outdoor installation, the light mounts via a 1/2-inch NPT pipe connection and is certified by UL, cUL, and Marine standards for Class I, Division 2 locations.
Key Features:
- Electraray Series LED: Provides high-output LED signaling for hazardous locations.
- Wide Voltage Range: Operates on 120–240 VAC for versatile installation.
- Blue Dome Color: Delivers bright, attention-getting visual alerts.
- Long Service Life: LED light source rated for 50,000 hours of operation.
- Environmental Protection: NEMA 4X, IP66, and IP69K enclosure ensures durability in harsh conditions.
- Configurable Mode: Default flashing operation with option for steady-burn.
- Mounting Options: Supports 1/2-inch NPT pipe mounting for secure installation.
- Certified Safety: UL Listed, cUL Listed, and Marine Listed for hazardous locations.
The 225XL-120-240B delivers the reliability and precision required for hazardous location visual signaling in industrial and marine environments.
