Description

The Allen-Bradley 194R-J30-1753S is an IEC Disconnect Rotary Switch designed for reliable and safe disconnection of electrical circuits. This fused rotary switch is part of the Bulletin 194R series and supports UL Class J and CSA Type HRCI-J fuses. It is rated for 30 Amps and 600 Volts AC, providing protection and isolation in industrial control systems.





Technical Specifications

Condition	New/Never Used Surplus
Brand	Allen-Bradley
Category	General Purpose Switches
Part Number	194R-J30-1753S
Subcatecory	Electrical Disconnect Switches
Actuator	No Handle
Connection Type	Screw
Mounting Type	4-Hole Front
Standard	CCC,KC
Voltage	600 Volt
Amperage	30 Amp
Indicator	Fuse Status Indication
Number of Poles	3 Pole
Weight	1.12 kgs





Information About 194R-J30-1753S

The 194R-J30-1753S is built to meet the demanding needs of industrial applications, offering robust performance and enhanced safety. It features screw-type terminals for secure wiring and is designed for front mounting with a 4-hole pattern. While the actuator handle is not included, it supports long turning handle operation. This disconnect switch is ideal for motor control centers, panel installations, and service entrance equipment where fused protection and disconnect capability are essential.

Key Features:

• 30 Amp Current Rating: Suitable for light to medium-duty power disconnection applications.

• UL Class J and CSA HRCI-J Fused Compatibility: Ensures compliance with North American standards for electrical protection.

• Fuse Status Indication: Allows quick identification of blown fuses, enhancing safety and reducing downtime.

• 3-Pole Configuration: Provides effective isolation for three-phase systems.

• 600 Volt AC Rating: Supports high-voltage industrial environments.

• Open Style Design: Ideal for integration into enclosed electrical panels.

• Screw-Type Connection Terminals: Ensure secure and easy wiring.

• 4-Hole Front Mounting: Standardized mounting pattern for simplified installation.

The 194R-J30-1753S is ideal for applications requiring compact, reliable, and fused disconnect solutions with visual fuse monitoring.
