Description

The Allen-Bradley 193-ERID is a Remote Indication Display accessory designed for use with the E1 Plus Overload Relay system. This device enables users to remotely monitor trip status and reset conditions without direct access to the relay itself.





Technical Specifications

Condition	New/Never Used Surplus
Brand	Allen-Bradley
Category	Measurement and Indicators
Part Number	193-ERID
Subcatecory	Indicator Displays
Type	Remote Indication Display
Mounting Type	22 mm Push Button Cut-out
Voltage Rating	Up to 300 Volts
Compatible Modules	193-ERR, 193-EPT, 193-EJM, 193-EGJ, 193-EGF
Functionality	Remote Indication & Remote Reset
Application	Motor Overload Relay Systems (E1 Plus)
Weight	0.1200 lb





Information About 193-ERID

The 193-ERID display is compatible with side-mount protection modules such as 193-ERR, 193-EPT, 193-EJM, 193-EGJ, and 193-EGF. It offers reliable visual status indication and reset functionality, enhancing the safety and accessibility of motor protection systems. Designed for industrial applications, it supports voltages up to 300V and allows operators to respond quickly to fault conditions.

Key Features:

• Remote Indication: Provides visual status feedback for motor overload trips.

• Remote Reset Capability: Allows users to reset the overload relay without opening the control cabinet.

• Compact Design: Fits standard 22 mm push button cut-outs for quick and easy panel integration.

• High Voltage Support: Operates with systems up to 300 Volts.

• Compatibility: Works with a variety of E1 Plus protection side-mount modules.

• Enhanced Accessibility: Improves user safety by reducing the need for physical access to relay modules.

The 193-ERID is ideal for applications where remote visibility and reset functionality are necessary for efficient motor protection management.
