Description
The Eaton Bussmann 15CLE-100E is a medium-voltage, E-rated current-limiting fuse designed for transformer and distribution system protection. Rated at 15.5 kV and 100 amps, it provides dependable overcurrent protection for indoor and outdoor installations. With a 63 kA interrupting capacity and single-barrel CLE construction, this fuse ensures durable and consistent performance in demanding electrical environments.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Eaton Bussmann |
| Category |
Fuse |
| Part Number |
15CLE-100E |
| Subcategory |
E-Rated Medium Voltage Fuse |
| Series |
CLE |
| Voltage Rating |
15.5 kV |
| Current Rating |
100 A |
| Interrupting Capacity |
63 kAIC |
| Fuse Class |
E |
| Fuse Type |
Current-Limiting |
| Construction |
Single Barrel |
| Mounting Type |
Ferrule |
| Clip Center |
21 in |
| Diameter |
3 in |
| Length |
23.9 in |
| Certifications |
IEEE Std. C37.41 |
| Application |
Transformer and Distribution Circuit Protection |
| Installation Type |
Indoor/Outdoor |
| Country of Origin |
Dominican Republic |
| Weight |
13.15 lb |
Information About 15CLE-100E
The 15CLE-100E is part of the Eaton Bussmann CLE Series, a line of high-performance fuses engineered for medium-voltage transformer and feeder applications. Built with a single-barrel ferrule design, this model offers robust construction and precise current-limiting capabilities under fault conditions. It complies with IEEE Std. C37.41, ensuring standardized performance and safety across utility and industrial applications. With its E-rating classification, the 15CLE-100E is ideal for protecting circuits that experience temporary overloads without unnecessary interruptions.
Key Features:
- Voltage Rating: 15.5 kV — Designed for medium-voltage distribution and transformer applications.
- Current Rating: 100 Amps — Provides optimal circuit protection for transformer and feeder systems.
- Interrupting Capacity: 63 kAIC — Handles high fault currents safely without compromising performance.
- E-Rated Classification: Ensures predictable time-current characteristics for overload protection.
- Single-Barrel Design: Offers compact installation with strong mechanical durability.
- Ferrule Mounting: Provides secure connection and simplifies installation in CLE-compatible holders.
- Standards Compliance: Tested and certified per IEEE Std. C37.41 for reliability and performance.
- Indoor/Outdoor Use: Built for versatility in both protected and exposed operating environments.
The 15CLE-100E delivers the reliability and precision required for safe and efficient medium-voltage electrical system protection.
