Description
The Allen-Bradley 140MG-H8E-C60 is a motor protection circuit protector designed to provide reliable short-circuit and overload protection for motors.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Allen-Bradley
|
| Category |
|
| Part Number |
140MG-H8E-C60 |
| Subcatecory |
Time Delay Relay |
| Amperage |
60 Amp |
|
Number of Poles
|
3 Pole |
|
Type
|
Motor Circuit Protector |
|
Frame
|
125 A, H-Frame |
|
Standard
|
CCC,RCM |
|
Rated Operating Voltage
|
200 to 480 Volts AC |
|
Power Rating
|
22 Kilowatts |
|
Weight
|
3.79 lbs |
Information About 140MG-H8E-C60
The Allen-Bradley 140MG-H8E-C60 is a compact, high-performance motor protection circuit breaker designed for reliable overload and short-circuit protection in industrial motor control applications.
Key Features:
- Frame Size: H Frame (compact design for space-saving installation)
- Rated Current: 60 A
- Poles: 3
- Rated Operating Voltage: 200–480V AC
- Interrupting Capacity: Up to 65 kA at 480V AC
- Protection Type: Thermal (overload) and Magnetic (short-circuit)
- Thermal Trip: Adjustable
- Magnetic Trip: Fixed
- Trip Indication: Visible status indicator for quick diagnostics
- Standards Compliance: UL 489, CSA C22.2 No. 5
- IP Rating: IP20 (guarded terminals)
- Dimensions: 130 mm (H) × 90 mm (W) × 82.5 mm (D)
- Operating Temperature: –20°C to +50°C (–4°F to +122°F)
This motor protection circuit breaker is ideal for safeguarding motors in demanding industrial environments, offering high interrupting capacity, easy adjustment, and compact installation for efficient motor control and protection.
