Description
The Siemens 14-193-100-582 is a Type 700 definite-purpose DC contactor designed for high-current switching in industrial power systems. With a 125 VDC coil and a 1000 A continuous current rating, it delivers reliable performance in demanding direct current (DC) applications.
Technical Specifications
|
Condition
|
New/Never Used Surplus
|
| Brand |
Siemens
|
| Category |
|
| Part Number |
14-193-100-582 |
| Subcatecory |
|
| Contactor Class |
Definite Purpose, Type 700 |
| Voltage Rating |
600 VDC (1000 VDC Max) |
| Current Rating |
1000 A (1250 A Max) |
| Coil Voltage |
125 VDC |
| Auxiliary Contacts |
2 NO / 2 NC |
| Over-Current Hold-In |
Not Included |
| Weight |
11.34 kgs |
Information About 14-193-100-582
The 14-193-100-582 DC contactor is engineered for use in 600 VDC systems, with a maximum voltage capacity of 1000 VDC. It features a 125 VDC coil for control operation and supports 2 normally open (NO) and 2 normally closed (NC) auxiliary contacts, offering flexibility for status feedback and interlocking circuits. The unit does not include over-current hold-in, simplifying control logic where external protection devices are used.
Key Features:
-
High Current Switching (1000 A Continuous): Supports demanding DC loads in industrial and energy systems
-
Voltage Rating: Operates in circuits up to 600 VDC (1000 VDC max)
-
125 VDC Coil Voltage: Enables consistent control in DC-powered systems
-
2 NO / 2 NC Auxiliary Contacts: Flexible for control circuit integration
-
Without Over-Current Hold-In: Simplifies control where external protection is preferred
The 14-193-100-582 provides powerful DC switching capability with durable construction and flexible control options.
