Description
The 104-C30D22 is an Allen-Bradley 3-pole reversing contactor rated for 30A (AC-3). It features a 24V DC coil and includes 2 Normally Open (NO) and 2 Normally Closed (NC) auxiliary contacts.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Allen-Bradley
|
| Category |
|
| Part Number |
104-C30D22 |
| Subcatecory |
|
| Amperage |
30 Amp at 400 VAC-3, 65 Amp at 400 VAC-1 |
| Connection Type |
Screw-Type Terminals |
| Current |
30 Amp |
| Standard |
C-TICK,CCC,CE,CSA,CUL,GOST,KC,UL |
| Voltage |
230-690 VAC at 50 Hz, 115-575 VAC at 60 Hz |
| Coil Voltage |
110 V |
| Contact Configuration |
1 NO, 1 NC Auxiliary |
| Power Rating |
15 kW |
| Weight |
2.45 lbs |
Information About 104-C30D22
The 104-C30D22 is a robust reversing contactor from Allen-Bradley, designed for dependable motor control in demanding industrial applications.
Key Features:
- Type: Reversing Contactor
- Series: 104-C
- Current Rating: 30 Amperes (AC-3 duty)
- Poles: 3-pole
- Coil Voltage: 24V DC
- Auxiliary Contacts: 2 Normally Open (2 NO) and 2 Normally Closed (2 NC) contacts included
- Control Function: Enables reversing operation for motors, allowing forward and reverse control
- Mounting: DIN rail or panel mountable for flexible installation
- Mechanical Durability: High mechanical and electrical endurance for frequent switching operations
- Certifications: UL, CSA, CE
- Applications: Suitable for motor reversing circuits in machinery, conveyors, hoists, and other industrial automation systems requiring reliable direction control
The 104-C30D22 offers a compact, durable solution for motor reversing applications, combining ease of installation with reliable, high-performance operation.
