Description
The Allen-Bradley 100S-C30EJ14C is a 30 A Safety Contactor designed for use in safety circuits requiring reliable switching and control. It operates with a 24 VDC electronic coil and includes a built-in diode for improved coil protection.
Technical Specifications
|
Condition
|
New/Never Used Surplus
|
| Brand |
Allen-Bradley |
|
Category
|
|
|
Part Number
|
100S-C30EJ14C
|
| Subcatecory |
|
| Amperage |
30 Amp at 400 VAC-3, 65 Amp at 400 VAC-1 |
| Contact Configuration |
1 NO, 4 NC Auxiliary |
| Current |
30 Amp |
| Standard |
C-TICK,CCC,KC |
| Voltage |
230-690 VAC at 50 Hz, 115-575 VAC at 60 Hz |
| Coil Voltage |
24 V |
| Power Rating |
15 kW |
| Type |
|
| Used With |
DIN Installation Panels |
| Weight |
1.4500 lb |
Information About 100S-C30EJ14C
The 100S-C30EJ14C is part of the Allen-Bradley 100S series, which is known for delivering high reliability and compliance with safety standards. These contactors are designed to handle 30 Amps at 400 VAC-3 and 65 Amps at 400 VAC-1, ensuring durability and performance in demanding environments. The built-in diode provides enhanced coil protection, improving longevity and minimizing electrical noise.
Key Features:
-
30 Amp Safety Contactor: Designed to manage up to 30 A at 400 VAC-3 and 65 A at 400 VAC-1 for high-performance switching.
-
Electronic Coil with Diode: Features a 24 VDC coil with an integrated diode for coil protection, reducing electrical interference and extending component life.
-
Robust Contact Configuration: Equipped with 3 NO, 1 NO, and 4 NC auxiliary contacts for flexible circuit integration.
-
Wide Voltage Range Support: Supports input voltages ranging from 230-690 VAC at 50 Hz and 115-575 VAC at 60 Hz for versatile application compatibility.
-
High Power Rating: Capable of handling up to 15 kW of power output.
-
Safety Compliance: Certified to meet international safety standards including C-TICK, CCC, and KC for global reliability.
-
Industrial Durability: Engineered to ensure secure and reliable performance in industrial automation and control applications.
The 100S-C30EJ14C is ideal for use in safety circuits, ensuring dependable switching for emergency stop systems, safety interlocks, and control panels.
