Description
The Allen-Bradley 100-C97DJ10 is a 97 Amp IEC contactor designed for reliable switching of motor loads in industrial applications. It features a robust 3-pole configuration with a 24 V DC coil and integrated diode for safe and efficient operation.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Allen-Bradley
|
| Category |
|
| Part Number |
100-C97DJ10
|
| Subcategory |
Contactor |
| Amperage |
97 A |
| Coil Voltage |
24 V DC |
| Connection Type |
Screw-Type Terminals |
| Contact Configuration |
3 NO main poles, 1 NO & 1 NC auxiliary contacts |
| Number of Poles |
3 Pole |
| Standard |
CCC, CE, CUL, GOST, KC, UL |
| Terminal Type |
Screw Terminals |
| Voltage |
0-24 V DC |
| Diode Protection |
Integrated Diode |
| Weight |
3.2800 lb |
Information About 100-C97DJ10
The 100-C97DJ10 belongs to Allen-Bradley's IEC contactor series, offering high performance for controlling three-phase motors. Its 97 Amp current rating makes it suitable for medium- to heavy-duty motor load switching. The device comes equipped with a 24 V DC coil that includes an integrated diode for protection against voltage spikes and ensuring long-lasting operation. Featuring screw-type terminals for secure connections, this contactor is designed for straightforward installation. It also includes 1 NO (normally open) and 1 NC (normally closed) auxiliary contacts, providing versatile control options for signaling and feedback.
Key Features:
- Coil Voltage: Operates on 24 V DC with integrated diode protection, enhancing reliability and safety during switching operations.
- Current Rating: Capable of handling 97 Amps, suitable for switching medium- to heavy-duty motor loads in industrial applications.
- Contact Configuration: Features 3 normally open main poles and auxiliary contacts with 1 NO and 1 NC, supporting various control circuit designs.
- Terminal Type: Screw terminals for secure and reliable wiring, simplifying installation and maintenance.
- Standards Compliance: Meets global standards including CCC, CE, CUL, GOST, KC, and UL, ensuring compatibility with international industrial systems.
The 100-C97DJ10 offers a compact and reliable solution for motor control applications, delivering high performance and durability for diverse industrial uses.
