Description
The Allen-Bradley 100-C85D00 is an IEC-rated contactor designed for controlling electric motors and other loads in industrial applications.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Allen-Bradley |
| Category |
Contactors & Starters |
| Part Number |
100-C85D00 |
| Subcategory |
|
|
Amperage
|
85 Amp |
|
Connection Type
|
Screw-Type Terminals |
|
Current
|
85 Amp |
| Number of Poles |
3 Pole |
| Standard |
C-TICK,CCC,CE,CSA,CUL,GOST,KC,UL |
| Terminal Type |
Screw Terminals |
| Voltage |
230-690 VAC at 50/60 HZ, 440 VDC |
| Coil Voltage |
110 V |
| Contact Configuration |
3 Normally Open Poles |
| Mounting Type |
35 mm DIN Rail |
| Power Rating |
25 kW |
| Temperature Rating |
-25 to 60 degrees C |
| Type |
Contactor |
| Weight |
2.43 lbs |
Information About 100-C85D00
The Allen-Bradley 100-C85D00 is a compact IEC contactor designed for controlling electric motors and other industrial loads. It is part of the 100-C series, known for space-saving design, high performance, and easy integration into motor control systems.
Key Features:
- Application: Designed for use in industrial motor control applications such as conveyors, pumps, fans, and compressors, with a rated operational current of up to 85 A (AC-3 duty).
- Configuration: 3-pole contactor with no auxiliary contacts (D00 configuration), supporting flexible customization with optional add-on accessories.
- Coil Voltage: Equipped with a dual-frequency coil rated at 110 V AC (50 Hz) / 120 V AC (60 Hz), offering compatibility across global standards.
- Construction: Built with a rugged, compact design and screw-type terminals, allowing reliable performance and ease of installation in confined control panel spaces.
- Mounting: Supports both DIN rail and panel mounting for versatile installation options in MCCs and control cabinets.
- Certifications: Complies with CE, UL, and CSA standards, ensuring global application and regulatory compliance.
- Integration: Designed for seamless use with Allen-Bradley overload relays and automation components, enabling efficient motor protection and control system architecture.
The 100-C85D00 is a reliable and flexible solution for industrial motor control. With its high current capacity, compact footprint, and integration-ready design, it’s ideal for engineers and OEMs seeking efficient control panel configurations without compromising on performance or safety.
