Description
The Allen-Bradley 100-C23EJ10 is a compact IEC contactor designed for reliable control of three-phase motors and other electrical loads. It offers a 23 A current rating and a 24 V coil, ensuring efficient performance in industrial automation systems.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Allen-Bradley
|
| Category |
|
| Part Number |
100-C23EJ10
|
| Subcategory |
Contactor |
| Series |
100-C |
| Rated Current (3-phase) |
23 Amp at 400 VAC |
| Rated Current (1-phase) |
32 Amp at 400 VAC |
| Coil Voltage |
24 V AC/DC |
| Frequency |
50/60 Hz |
| Power Rating |
11 kW |
| Contact Configuration |
1 NO Auxiliary |
| Terminal Type |
Screw-Type Terminals |
| Voltage Range |
230-690 VAC at 50 Hz, 115-575 VAC at 60 Hz |
| Standards Compliance |
UL, CE, CSA, CCC, C-TICK, KC, GOST |
| Weight |
0.8900 lb |
Information About 100-C23EJ10
The 100-C23EJ10 is part of Allen-Bradley’s 100-C series, a range of IEC contactors built for medium-duty motor control applications. This model is rated for 23 A at 400 VAC (3-phase) and 32 A at 400 VAC (single-phase), making it ideal for controlling motors up to 11 kW. It features a 24 V coil voltage, compatible with standard low-voltage control systems operating at 50 or 60 Hz. This contactor is equipped with 1 normally open (NO) auxiliary contact for signaling or interlocking. Its screw-type terminals ensure secure wiring, and the contactor is designed to operate within a wide voltage range of 230-690 VAC at 50 Hz or 115-575 VAC at 60 Hz.
Key Features:
- 23 A Rated Current (3-phase): Supports reliable switching of motors and resistive loads.
- 11 kW Power Rating: Suitable for controlling medium-sized motors and industrial equipment.
- 24 V Coil Voltage: Ensures compatibility with modern control circuits.
- 1 NO Auxiliary Contact: Provides flexibility for signaling or interlocking functions.
- Wide Voltage Range: Operates on 230-690 VAC at 50 Hz and 115-575 VAC at 60 Hz, suitable for global installations.
- Screw-Type Terminals: Secure and straightforward wiring, minimizing installation time.
- Robust IEC Design: Compact size allows for space-efficient integration into control panels.
- Compliance with International Standards: Meets UL, CE, CSA, CCC, C-TICK, KC, and GOST standards.
- Reliable Performance: Built for demanding industrial environments with consistent switching capability.
- Modular Accessories: Supports integration with overload relays and other control components.
The 100-C23EJ10 offers dependable, versatile motor control solutions for diverse industrial applications.
